SIZE & PERFORMANCE
|
Achievable Accuracy
|
Up to 0.1 mm (below 0.1mm achievable on smaller parts) |
|
Working Area
|
1330 x 2700 mm |
| Overall footprint |
1750 x 3150 x 1250 mm |
| Z clearance height |
|
|
Typical cutting parameters (softwood)
|
- Feedrate: 7000 mm/min - Depth of cut: 5 mm - Spindle speed: 20,000 rpm - Carbide cutter 3 flutes 6 mm |
| Maximal axial speed | 25,000 mm/min |
|
Maximal traverse speed
|
30,000 mm/min |
| Spindle | 2.2 kW air cooled Speed from 5000 to 24000 rpm Computer-controlled ER20 collets |
| Power consumption | 1x 230VAC (max. power: 3.5 kW with spindle, +0,55 kW with dust collection) |
MECHANICS
|
Structure
|
- Steel plates (8 & 10mm) - Aluminium profiles (30x60mm & 60x60mm) |
| Linear guide system | Double prismatic rail HGR20 |
| Drive System |
|
| X and Z-Axis | Ballscrews 16 mm ±50 µm / 300 mm (C7) |
| Y-Axis | Mod 2 Rack and pinion ±26 µm / 1000 mm (DIN5 / Q5) |
ELECTRONICS
|
Motors
|
- Nema34, 6 A, 4.5 Nm (X & Y) - Nema23, 5 A, 2.2 Nm (Z) |
|
Motor drivers
|
- 32-bit DSP - 72 VDC 8.4 A - Microstepping 1/32 - Idle current control - Speed smoothing coefficient (acceleration/deceleration) |
| Onboarded computer | Raspberry Pi 4B (2 Gb RAM) |
| Ports | - 3 USB ports - 1 Ethernet port - 1 HDMI port |
| Connectors | - Neutrik XLR (motors and sensors) - GX12 (inputs/outputs) |
| Interface Unit (not included) | - 13.3" TFT IPS capacitive touchscreen - Custom Bluetooth keypad |
| Connectivity | - WiFi (2.4 GHz and 5.0 GHz IEEE 802.11ac ) - Bluetooth (5.0) - Gigabit Ethernet |
| Limits Sensors | Inductive sensors (6x) |
| Tool length sensor | Touch plate with crocodile clip |
|
Controller
|
PlanetCNC Mk3/4 |
CONTROL SOFTWARE
|
PlanetCNC TNGv2
|
- Embedded G-code generator/editor - Toolpath visualization - Import toolpath from 2D files (dxf, png,...) - Advanced motion interpolation - Simulation mode - Manual Data Input mode (MDI) - Automatic homing and square gantry - Automatic tool length measuring and probing - Feed & speed override - Customizable view, scripts and M-codes |
| CAM compatibility | Compatible with all CAM software available on the market (advising Fusion360) |
